Desain pipa listrik yang diperuntukkan bagi proyek kabel bawah tanah sangat diperlukan sebagai acuan untuk pengaplikasiannya. Selain itu, perlu diperhatikan beberapa faktor lainnya supaya pemasangan kabel dapat berjalan lancar. Penasaran? Berikut informasi lengkap yang harus Anda ikuti sampai akhir.
Apa Itu Desain Pipa Listrik untuk Proyek Kabel Bawah Tanah?
Desain pipa listrik merupakan rancangan instalasi pipa untuk listrik dengan kabel bawah tanah yang digunakan dalam memudahkan proses pengerjaan. Dalam desain tersebut, terdapat gambar dan petunjuk mengenai objek yang digunakan.
Metode yang digunakan adalah pemadatan lapis-berlapis dengan ukuran setiap 30 cm. Selain itu, dalam desain terdapat petunjuk untuk batu yang digunakan, yakni batu pecah 10 cm, sirtu kelas A, batu pecah 2.5 cm, serta aspal atau hotmix. Beberapa material ini digunakan pada lapisan atas.
Selanjutnya, pada lapisan tengah memiliki warning tape yang merupakan tanda area atau lokasi. Sedangkan di bagian bawahnya, terdapat material berupa pasir untuk pipa dan kabel tanah. Pipa yang digunakan sesuai dengan pilihan Anda.
Ini merupakan salah satu contoh desain pipa listrik yang bisa Anda ikuti sebagai acuan. Namun, dengan mengenali prosedur pemasangan kabel bawah tanah, Anda dapat membuat saluran pipa yang baik sesuai kebutuhan.
Prosedur Pemasangan Pipa Listrik untuk Kabel Bawah Tanah
Seperti apa prosedur pemasangan kabel bawah tanah yang benar dapat Anda jadikan sebagai acuan? Berikut Langkah-langkahnya:
1. Membuat Kedalaman Tanah
Hal pertama yang harus Anda lakukan adalah membuat kedalaman tanah. Ini sangat penting untuk menentukan keberlangsungan proyek kabel bawah tanah. Proses pembuatan lubang atau urugan berfungsi sebagai pelindung pipa yang berisikan kabel listrik. Jika ingin memulainya, Anda bisa menggali tanah dengan ukuran tanah dan jarak sesuai dengan kondisi permukaan tanah maupun jalan.
2. Lapisan Tanah
Bagian yang tidak kalah penting dari kedalaman tanah adalah lapisannya. Sebelum menempatkan pipa ke tanah yang berbatu, Anda harus melapisi bagian bawah dengan tanah setinggi 10 cm. Selanjutnya ratakan sampai semua bagian menggunakan pasir halus dengan ketebalan serupa. Namun jika lapisan tanah sudah dipastikan aman, Anda bisa meletakkan pipa listrik yang digunakan.
3. Pemasangan Kabel
Pemasangan kabel juga memiliki prosedur yang perlu untuk Anda ikuti, yakni dengan memeriksa isolasi kabel dengan megger sebagai pemeriksaan pencegahan adanya kerusakan.
Setelah itu, penggulung kabel harus diputar searah dengan tanda panah dan diambil dari puncak bagian penggulung.
Jika perlu dipindahkan, pastikan penggulung kabel dipindahkan dengan roda-roda kabel. Pipa yang berperan sebagai pelindung kabel, kemudian dijadikan wadah dengan satu kabel primer dan tiga kabel sekunder.
4. Menutup Permukaan
Tutup permukaan pipa sampai jarak yang ideal. Lakukan secara merata menggunakan tanah atau pasir halus, mulai dari bagian samping pipa sampai penuh dan menyeluruh. Ini bertujuan supaya pipa tidak mudah bergeser dan tetap berada pada kondisi yang stabil.
5. Proses Finishing
Setelah lapisan untuk menutupi pipa berukuran 30 cm di atasnya, Anda dapat membuat lapisan atas urugan yang tertutup rapi dan aman. Anda bisa menggunakan alat perata tanah untuk melakukannya. Perlakuan yang baik dan benar mengikuti desain, beserta prosedur akan membuat instalasi listrik bermanfaat.
